Minimalist Window – Sliding | Vitrocsa

Vitrocsa, who created the minimalist window, has developed innovative expertise in this domain. The many systems and solutions developed in-house guarantee original products, all manufactured to Swiss Made quality standards.

The sliding aluminum windows by Vitrocsa is a unique horizontal opening solution.

The structure is anodized 25-micron aluminum alloy, in a natural color finish. As an option, the thermo-lacquered or anodized versions are available in an infinite choice of colors. The roller bearing system for these architectural windows is made from stainless steel specially adapted for projects near the sea.

Fixed or sliding, this minimalist window design feature a vertical from of 22 mm and is only limited by the maximum surface area of the glass. Button-locking is available with two-point locking and cylinder locking with key. Motorization is possible.

The Vitrocsa sliding aluminum windows is available in versions suited to a range of applications: curved, invisible frame, pocket and open-angle.

APPLICATIONS

CURVED

The curved application supports a radius of 3 meters for mobile elements and 1.5 meters for fixed.

This application is only available with anodized treatment to guarantee the precision of the curve.

Invisible Frame

This application removes the need for an internal or external architectural enclosure. It features 32 or 44 mm double or triple glazing, and sliding window surfaces of up to 18 m².

Pocket

It is possible to conceal one or more sliding panels in a closed and isolated space.

Open Angle

This solution frees the angle from any jambs. All combinations of rails are possible, for example a combination of two and three rails.
