Designed by 3GATTI,  ZEBAR is a live hangout located in KIC plaza, Chuangzhi Tiandi, Songhu road, Shanghai, China. The client, Jim Dandy wanted a live bar that would include bar, restaurant, live music stage area, lounge area, dining area, kitchen, toilets. The project is a pretty straightforward construction of a computer modeling operation. The designers made an amorphous shape, and subtracted that shape from a series of parallel solid walls that fill the project’s boundaries. The effect of the stripes is very graphic and bold, but I would imagine the lines get a little more blurry after a few drinks. more details about the project come from the architect after the jump.

Arch2O ZEBAR 3GATTI  -60

Courtesy of 3GATTI  – Photography of Daniele Mattioli


This project was born in 2006 when a Singaporean movie director and an ex musician from south of China decided to open a live bar in Shanghai. The budget was very low but the client was incredibly good and open-minded to us. The schedule was very tight and fortunately they liked immediately one of the first concepts I proposed to them: a caved space formed from of a digital Boolean subtraction of hundreds of slices from an amorphic blob.

Arch2O ZEBAR 3GATTI  -61

Courtesy of 3GATTI  – Photography of Daniele Mattioli


The idea looks complex but actually is very simple and was born naturally from the digital 3D modelling environments where me and others enjoy playing with virtual volumes and spaces. The space was subdivided into slices to bring it back from the digital into the real world; to give a real shape to each of the infinite sections of the fluid rhino nurbs surfaces.


Arch2O ZEBAR 3GATTI  -57

Courtesy of 3GATTI  – Photography of Daniele Mattioli

In Europe the natural consequence of this kind of design will be giving the digital model to the factory and thanks to the numeric control machines cut easily the huge amount of sections all different from each other. But we were in China where the work of machines is replaced by the work of low paid humans. Using a projector they placed all the sections we drew on the plasterboards and then cut each of them by hands. The cost was surprisingly low and the sense of guilt towards the workers higher.

Arch2O ZEBAR 3GATTI  -63

Courtesy of 3GATTI  – Photography of Daniele Mattioli

The construction was incredibly fast and was almost finished in a couple of months, when we discovered the naïve clients didn’t have any business plan and the site remained closed for 3 years and was finally completed and opened in 2010 when they discovered how to run the business.

Credits and Info:

Architecture firm: 3GATTI
Chief architect: Francesco Gatti
Project manager: Summer Nie
Collaborators:Nicole Ni, Chen Qiuju, Kelly Han, Chen Han Yi, Lu Cheng Yuan, Jessie Zhengxin, Ronghui Chen, Vivian Husiyue, Aurgho Jyoti
Programme: Bar, restaurant, live music stage area, lounge area, dining area, kitchen, toilets.
Contractor: Eric Liang
Client: Jim Dandy
Location: KIC plaza, Chuangzhi Tiandi, Songhu road, Shanghai
Total area: 569 m²
Design period: Autumn 2006
Construction period: Spring 2008
Bar opening: November 2010
Materials: white epoxy, black concrete, plywood and plasterboard
Photographer:Daniele Mattioli
